Product Overview
This is an industrial-grade integrated water treatment system built to produce stable high-purity water for various industrial needs. It includes four core working modules: the pretreatment section, RO unit, electrical control system, and piping assembly. These parts work together to process raw water into qualified pure water that meets your strict production requirements.
Feature Highlights
High Purity Output
It delivers purified water with conductivity ≤10 μS/cm, meeting strict high-end industrial purity requirements.
01
High Rejection
It hits ≥99% salt rejection, cutting water waste and your long-term operation cost.
02
Robust Construction
The system uses SS304 stainless steel for key wetted parts. This corrosion-resistant material greatly extends the system's service life.
03
Comprehensive Pretreatment
It has full pretreatment modules to protect RO membranes, effectively extending the membranes' service life.
04
Efficient Power Usage
Its total power consumption stays under 8.5kW, cutting your daily electricity bills effectively.
05
Technical Specifications
All product parameters are organized in standard tables below for your clear check:
|
Core System Parameters |
|
|
Parameter |
Specification |
|
System Model |
YN-RO-6 |
|
System Capacity |
6 m³/h |
|
Recovery Rate |
≥70% |
|
Desalination Rate |
≥99% |
|
Outlet Conductivity |
≤10 μS/cm |
|
Operation Pressure |
1.0-1.6MPa (≈10–16 bar) |
|
Total Installed Power |
≤8.5 kW |
|
Max Feed Water TDS |
≤2000 ppm |
|
Feed Water Temperature Range |
5–45 °C |
|
Feed Water Turbidity Limit |
≤1 NTU |
|
SDI (15 min) |
≤3 |
|
Pretreatment Parts Parameters |
|
|
Part Name |
Specification |
|
Raw water tank |
SS304 material, 1 set |
|
Multi-media filter |
SS304 material, 1 set |
|
Activated carbon filter |
1000×1900, SS304 material, 1 set |
|
Cartridge filter |
240×1500 F,RP body, 1 set |
|
RO System Parts Parameters |
|
|
Part Name |
Specification |
|
RO membrane |
8040 high-rejection type, 6 pieces |
|
Membrane housing |
8040-2, FRP material, 3 units |
|
Conductivity meter |
0-2000μS/cm range, 2 units |
|
Electrical Parts Parameters |
|
|
Part Name |
Specification |
|
Control system |
PLC automatic control, 1 set |
|
Control cabinet |
Standard configuration, 1 unit |
|
Piping and Storage Parts Parameters |
|
|
Part Name |
Specification |
|
Pipes and valves |
DN50/40/DN25/DN20/DN15, PN16, mixed SS304 and U-PVC, 1 lot |
|
Pure water tank |
SS304 material, 1 set |
Application Scenarios
Electronics Manufacturing
Electronics factories need ultra-pure water for production. This system delivers water with very low conductivity. It prevents impurities from damaging your circuit boards or components, and supports your stable production line.
Food and Beverage Processing
Food and beverage makers need clean, safe water for their products. This system removes harmful contaminants from raw water. It ensures your final products are safe and taste good, and helps you meet national and international food safety standards.
Laboratory Water Supply
Research labs need consistent pure water for tests and experiments. This system provides stable high-purity water. It helps you get accurate and reliable test results, and reduces the trouble of buying and storing bottled pure water.
Customization Options
Adjust flow rate
We can change the pure water output to match your production demand.
Material upgrade
Upgrade key parts to SS316L stainless steel for special corrosive or hygiene needs.
Advanced automation
Add PLC package for easier system monitoring and remote control.
OEM/ODM service
We support full custom design and branding based on your requirements.
Why Choose Us
We are a trusted water treatment supplier for global clients. Here are the core reasons you can choose us for your project:
10 Years of Manufacturing Experience
We have over 10 years of experience in the water treatment industry. We know how to build reliable systems that fit different global clients' needs.
Full International Certifications
We have obtained ISO9001 certifications. Our products meet international quality and safety standards.
Project Solutions
We offer full project solutions for all our clients. We handle everything from design, production, installation to after-sales service. You do not need to worry about any part of the whole project.
FAQ
Q1: Why does this RO-EDI system include a multi-media filter and a softener in pretreatment?
A1: The multi-media filter removes suspended solids, colloids, and large particles from raw water. It stops your RO membranes from getting clogged. The softener removes water hardness. It prevents scale from building up on the membranes. Both parts work together to protect the membranes and extend their service life.
Q2: Can we customize the equipment?
A2: Yes, you can. We offer core customization options to fit your specific needs. You can tell us your requirements, and we will make a suitable solution for you.
Q3: Is your company a trading company or a manufacturer?
A3: We are a direct manufacturer. We have our own R&D team, factory, and export team. We integrate R&D, production, and international trade. You can get factory-direct prices and professional one-stop support from us.
Q4: What kinds of raw water can this system handle?
A4: This system can handle many types of raw water, including tap water, well water, brackish water, and process wastewater. It can work stably as long as the feed water TDS is under 2000 ppm.
