Product Overview
This is our Hollow Fiber Ultrafiltration (UF) Membrane module. It is a professional, high-efficiency water filtration component built for all kinds of water treatment projects. It uses advanced hollow fiber technology to deliver reliable, consistent filtration performance. We offer multiple material options to fit different working conditions, so you can always get the right solution for your needs. This product is designed to help you get clean, safe filtered water easily, no matter what your project is.
Feature Highlights
- Precise filtration: It has a 0.03~0.1 micron pore size, which can effectively remove bacteria, colloids and most suspended solids to ensure stable output water quality.
- Durable material options: We provide PVDF materials. PVDF material has strong chemical resistance, working well even in harsh water environments.
- Wide working adaptability: It works stably across a pH range of 2-10, handling different types of feed water without performance loss.
- Easy system integration: It fits standard system setups. You do not need to modify your existing pipes or systems, which saves your installation time and cost.
Technical Specifications
|
Parameter |
Details |
|
Model Number |
2880 (custom models available) |
|
Membrane Type |
UF (Ultrafiltration) |
|
Fiber Material Options |
PVDF |
|
Pore Size |
0.03~0.1 micron |
|
Fiber Inner Diameter |
0.7mm |
|
Fiber Outer Diameter |
1.3mm |
|
Module Dimension |
250*1745mm |
|
Operating Temperature |
5-40 Centigrades |
|
Operating Pressure |
Less than 0.3MPa |
|
Max Tolerance Pressure |
0.5MPa |
|
pH Range |
2-10 |
Product Applications
Municipal Water Treatment
This module purifies municipal raw water. It removes bacteria and impurities to make the water safe for residents' daily use, helping you deliver qualified tap water to the public.
Sewage Treatment
It works perfectly for sewage treatment projects. It recovers usable water from sewage, reducing water waste and lowering your overall operation costs.
Industrial Wastewater Treatment
It treats industrial wastewater effectively. It filters out pollutants to help you meet local environmental discharge standards, and you can also reuse the treated water to cut your water costs.
RO System Pre-treatment
It acts as a reliable pre-treatment step for RO systems. It filters out large impurities to protect your RO membranes, extending their service life and reducing your maintenance costs.
Customization Options
Material selection
You can choose PVDF, PES or PAN fiber material to match your water quality and project requirements.
Size adjustment
We can adjust the module size and membrane area to fit your system's space and flow rate needs.
Flow rate customization
We can tune the module's design flux to match your project's processing capacity requirements.
OEM & private label
We support OEM service and private labels, helping you build your own brand in the local market.
Why Choose Us?
We have 10 years of manufacturing experience, with deep industry knowledge to deliver reliable products.
We are an ISO 9001 certified factory with strict full-process quality control.
We support flexible small orders. We accept trial orders with a minimum of 1 piece, so you can test our product before placing large orders.
Our modules are compatible with famous international brands' systems. You can replace old modules without changing your existing setup, saving your upgrade costs.
FAQ
Q: Do I need to modify my existing pipes and systems to use this product?
A: No. You do not need to modify your pipes or system PLC. It works with your existing system, keeping the same flow rate and high-quality filtrate. We can check details for your specific case if you need.
Q: Are you a manufacturer?
A: Yes. We are a professional manufacturer with our own factory, and you are welcome to visit us anytime.
Q: Do you offer OEM service?
A: Yes. We do OEM service. We can customize the product based on your needs, and we also provide private labels for you.
Q: Do you offer warranty for your products?
A: Yes. We offer 12 months warranty. The exact time depends on the product series, your water quality and operation conditions.
